So that it is possible to work in the optimal position in relation to the object, most boom lifts are equipped with a rotary working cage. This allows you to work quickly and economically. The working cage-change system allows the boom lifts to be converted for special applications. This means, of course, that a work cage for tree-pruning work has different requirements to those for mounting signs or other tasks which take place at a height.
Characteristics
- Versatile
- Extensive reach
- Large work baskets
- High stability
- High flexibility when changing site
Boom Lift |
AH |
Weight |
Lenght |
Width |
Height |
Max lateral reach |
Platform dimensions |
Loading capacity |
Amarok |
14,20m |
3.040kg |
6,40m |
1,95m |
2,43m |
4,80m |
0,76m x 1,15m |
200 kg |
Data Sheet |
LK 220 |
22,10 m |
3.500 kg |
7,20 m |
2,20 m, with supports 2,12 m x 3,50 m, eone side supports 2,85 m |
3,00 m |
14,00 m |
1,40 x 0,70 m |
200 kg |
Data Sheet |
LK 220 basketarm |
22,00m |
3.500kg |
6,92m |
2,12m, with supports 3,50m, one side supports 2,93m |
3,00m |
16,40m |
1,40 x 0,70m |
230kg |
Data Sheet |
LK 260 |
26,00m |
6.000kg |
front 7,40m back 9,40m |
2,30 m vehicle + supports |
basket front 3,40m, basket back 2,60m |
11,70 m |
1,30 x 0,70 m |
215 kg |
Data Sheet |
LK 270 |
27,00m |
3.500kg |
6,75m |
2,12m supports one side 2,85m width 3,50m |
3,00m |
14,80m |
1,40 x 0,70m |
230kg |
Data Sheet |
LK 280 |
28,00m |
7.490kg |
6,85m |
2,54m supports width 4,70m variabel |
3,30m |
20,00m |
1,62 x 0,82m |
320kg |
Data Sheet |
LK 290 |
28,80m |
3.500kg |
6,95m |
2,20m - 3,66m wide, suppports one side 2,93m |
3,02m |
16,20m |
Radius: 450° |
230kg |
Data Sheet |
LK 330 |
33,00m |
7.490kg |
8,79m |
2,54m supports width 5,30m variabel |
3,56m |
21,20m |
1,70 x 0,86m |
320kg |
Data Sheet |
LK350 |
35,00m |
18.000kg |
8,00m |
2,50m supports width 4,70m variabel |
3,84m |
30,00m |
2,00 x 0,82m |
350kg |
Data Sheet |
AK52/LK510 |
51,0/52,0m (crane mode) |
26.000kg |
11,32m |
2,55m wide, supports up to 8,0m variabel |
3,99m |
30,00m |
2,33 x 0,99m, up to 3,5m variable |
600kg |
Data Sheet |
